Standard Hardware
Durable type 304 stainless steel with superior corrosion resistance. Low-profile design minimizes gaps, ensuring privacy. Fully adjustable hinges and occupancy indicator latch provide functionality and affordability.
What is Standard Hardware
Ironwood’s standard hardware is made from type 304 stainless steel, which has good forming, welding, and drawing properties as well as strong corrosion resistance. Components are sheared, formed, welded, and finished with a number 4 brushed finish. This hardware package is inexpensive and allows for minimal gaps when installed.
What is Included in Standard Hardware
List of Hardware
Standard hardware includes all the hardware required for commercial restroom design, providing flexibility and easy installation.
One Ear Bracket
Two Ear Bracket
U Bracket
Alcove Clip
Coat Hook-Bumper
Pull
Indicator Latch-Keeper
Surface Mount Hinge
Deeper Dive & Resources
Discover detailed information about standard hardware to make informed decisions for your commercial restroom design.
Here are some considerations for standard hardware to determine its suitability for your commercial restroom project:
- This hardware allows for 3/8” minimum gaps
- The finish is number 4 brushed
- This hardware is flat, low profile, and square-edged
- Hinges are visible from the swing face of the door and hinge through bolts are visible from the non-swing face
Brackets
1 ear, 2 ear, U type, and alcove clip brackets are built from 18 gauge (0.046″ thick) type 304 stainless steel with a number 4 brushed finish.
Surface Mount Hinge
The hinge is built from 11 gauge (0.125″ thick) type 304 stainless steel with a number 4 brushed finish. Fully adjustable, cam and pintle. 3” wide by 2-1/2” tall.
Bar Type Pull
The pull is built from 13 gauge (0.094″ thick) type 304 stainless steel with a number 4 brushed finish. 8″ (200mm) overall length with 4″ (100mm) center to center and 2″ (50mm) tall.
Hook/Bumper
The combination hook and bumper is built from 304 stainless steel with a number 4 brushed finish. The hook includes an integrated black rubber bumper.
Latch
The occupancy indicator style latch with keeper is built from 13 gauge (0.094″ thick) type 304 stainless steel with a number 4 brushed finish.
Bracket Height and Depth
| 1 Ear | 2 Ear | U Bracket | Alcove | |
|---|---|---|---|---|
| Height inch/mm | 1.5 / 38 | 1.5 / 38 | 1.5 / 38 | 1.5 / 38 |
| Depth inch/mm | 2.5 / 64 | 2.5 / 64 | 1.5 / 38 | 2.375 / 60 |
Frequently Asked Questions
What finish is applied to the hardware?
All components have a number 4 brushed finish, providing a sleek and uniform appearance.
Are the hinges adjustable?
Yes, the door resting position can be adjusted with the hinge’s cam and pintle design, allowing easy alignment during installation and maintenance.
What type of latch is included in this package?
The package includes an occupancy indicator style latch with a keeper. This latch clearly indicates if a stall is occupied, preserving privacy.
Does this hardware require special maintenance?
Standard Hardware is designed for minimal maintenance. Regular cleaning with mild soap and water is typically sufficient.
Can this hardware be used with different partition materials?
Yes, Standard Hardware is versatile and can be used with various partition materials offered by Ironwood Manufacturing.
What is the main difference between continuous and standard?
Continuous hardware features longer, uninterrupted components, particularly the hinge, which runs nearly the entire door length for enhanced stability and durability.
What if I don’t want stainless steel factory finish?
Hardware and fasteners can be powder coated. Powder coat is available in bronze, black, and many other colors.
If you can’t find the answer you’re looking for, feel free to reach out to us directly and we’ll be happy to assist you!
